Pro Comp Suspension 6-Inch Stage I Radius Arm Drop Suspension Lift Kit with ES9000 Shocks (11-16 4WD 6.7L Powerstroke F-250 Super Duty)Find parts that fit my vehicle
Item SD1066
$0.00
7 Reviews
Our Price
$1,404.99 kit
Out of Stock
$199.00 Oversized Item Fee
Ship to: Columbus - 43215
Sorry, please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.
Will this fit your Vehicle?
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
Product Information
Features, Description, Reviews, Q&A, Specs & Installation
Features & Specs
- Stage 1 Suspension Lift Kit
- Provides 6 Inches of Lift Height for Both Front and Rear
- Creates a More Aggressive Look and Boosts Off-Road Performance
- ES9000 Front and Rear Shocks
- Specific Rate Front Coil Springs
- Rear Lift Blocks With U-Bolts and Add-a-Leaf Kit
- Comes With Sway Bar Drops and a Track Bar Relocation Bracket
- Includes Radius Arm Drop Brackets
- Maximum Tire Size of 35x12.50 Inches and Wheel Size of 20x10 Inches
- Maximum Wheel Backspacing of 5.50 Inches
- Direct, No-Weld Installation
- Comes With a Lifetime Warranty
- Fits 2011-2016 4WD Ford F-250 Super Duty With a 6.7L Engine
| Brand | Pro Comp Suspension |
| Lift Height | 6.00 Inch |
| Lift Kit Type | Suspension Lift |
| Lift Kit Max Tire Size | 35 Inch |
| Lift Kit Includes Shocks | Shocks Included |
Description
Improved All-Around Off-Roading Capabilities. If you want to boost your Ford Super Duty’s off-roading capabilities without breaking the bank, then this Pro Comp 6-Inch Stage 1 Suspension Lift Kit With ES9000 Shocks is a great choice. It provides 6 inches of additional ground clearance, which gives you room to install up to 35-inch tires and improves your truck’s off-road ground traction. The height also creates a more aggressive look and allows you to drive easily over minor obstacles. What’s more, this kit also comes with a steering stabilizer bracket and radius arm drop brackets. These parts help maintain proper steering geometry and that smooth, comfortable OEM ride quality.
ES9000 Front and Rear Shocks. These ES9000 shocks are Pro Comp’s baseline performance shocks, which significantly improves your truck’s stock damping capabilities. They feature a 10-stage, velocity sensitive valving, which means you’ll get a smooth and even ride whether you’re driving fast or slow. These shocks also sport .375-inch, nylon-banded pistons and a nitrogen gas-charged design for excellent performance both on and off the road.
Specific Rate Front Coil Springs. This stage 1 suspension lift kit comes with a set of new front coil springs to haul your truck up a full 6 inches off the ground. These heavy-duty springs are made from high-quality materials, ensuring that they can withstand rough trails without losing ride-height consistency. Coupled with the ES9000 shocks and a set of radius arm drop brackets, these coil springs ensure that you will experience a comfortable ride no matter where you’re driving.
Rear Lift Blocks and Add-a-Leafs. To match the 6-inch lift height provided by the front coil springs, Pro Comp included rear lift blocks and add-a-leafs with this stage 1 suspension lift kit. The 5.50-inch blocks can be easily placed on top of your truck’s OEM blocks, using the include U-bolt kit to provide extra support and keep the parts in place. Meanwhile, the leaf springs increase the rear load capacity of your truck.
Sway Bar Drops. Lifted trucks often become unstable because of the higher center of gravity. This problem is especially noticeable on the trails, where the roads are bumpier. To counter this problem, this lift kit comes with sway bar drops. These components help minimize body roll during fast cornering and turning, and also keep your truck stable and driveable even on rough terrains.
Track Bar Relocation Bracket. This lift kit also comes with a track bar relocation bracket. It helps eliminate excess side-to-side movements of the axle and keep the body of your truck in line with the suspension. This way, you will have a steadier ride. Along with the steering stabilizer bracket, this track bar relocation bracket also helps improve your truck’s steering control and response.
Bolt-On Installation. Pro Comp designed this lift kit for a direct fit with no welding required, although some drilling is needed to accommodate some components. Note that this lift kit requires professional installation and will take about 8 hours to finish mounting properly onto your vehicle.
Covered by a Lifetime Warranty. This stage 1 suspension lift kit comes with a lifetime warranty, which applies to all suspension products and components barring a few exceptions. If you have any questions regarding the terms and conditions of the warranty, kindly get in touch with the manufacturer.
Application. This Pro Comp 6-Inch Stage 1 Suspension Lift Kit With ES9000 Shocks can be installed on all 2011-2016 4WD models of the Ford F-250 Super Duty with a 6.7L engine.
Shop All 6 to 8 Inch Truck Lift Kits
Shop All Truck Parts And Accessories
Shop All Truck Lift Kits
Fitment:
DetailsPro Comp Suspension K4177B
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (2) Front Coil Springs
- (2) Rear Lift Blocks
- (1) U-Bolt Kit
- (4) ES90000 Front and Rear Shocks
- (2) Sway Bar Drops
- (1) Sway Bar Spacer
- (1) Steering Stabilizer Bracket
- (1) Track Bar Drop Bracket
- (1) Pitman Arm
- (1) Pitman Arm Tool
- (2) Bump Stop Spacers
- (2) Rear Sway Bar End Links
- (1) Rear Brake Line Mount
- (2) Front Brake Line Drop Brackets
- (2) Radius Arm Spacer Tubes
- (4) Radius Arm Drop Side Plates
- (2) Front Shock Mount Adapters
- (4) External Reservoir Mounting Kit
- (2) Limit Straps
- (4) Add-a-Leafs
- Complete Mounting Hardware
5.0
Customer Reviews (7)
Reviews of Pro Comp Suspension Suspension products have an average rating of 5.0 out of 5
Questions & Answers
No questions about this product yet.
Ask the First Question
Will It Fit My F-250
- 6.7L V8 Power-Stroke - 11, 12, 13, 14, 15, 16
