Find 3 Inch to 5 Inch Lift Kits for your F-250
Zone Offroad 4.50-Inch Suspension Lift Kit with Nitro Shocks (20-22 4WD 6.2L, 7.3L F-250 Super Duty)Find parts that fit my vehicle
Item SD11624
$0.00
51 Reviews
Our Price
$1,026.55 kit
Ship to: 43215
Please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.
Will this fit your Vehicle?
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Product Information
Features, Description, Reviews, Q&A, Specs & Installation
Features & Specs
- 4.50-Inch Suspension Lift Kit
- Increases Ground Clearance for Improved Off-Roading
- Nitro Shocks Included
- Rear Solid Cast Iron Blocks Included
- Twenty-Inch or Larger Wheels Recommended
- Fits 2020-2022 4WD 6.2L, 7.3L F-250 Super Duty Models
| Brand | Zone Offroad |
| Lift Height | 4.50 Inch |
| Lift Kit Type | Suspension Lift |
| Lift Kit Max Tire Size | 35 Inch |
| Lift Kit Includes Shocks | Shocks Included |
Description
Off-Road Ready. Give your Super Duty the ability to tackle any trail by installing a Zone Offroad 4.50-inch Suspension Lift Kit with Nitro Shocks. This Lift Kit works with the Stabilitrack System and will allow you to mount 35-inch tires, giving your truck a rugged off-road appearance. Whether you’re a serious off-roader, want to mount larger tires and wheels, or are just looking to give your rig a more beefed-up appearance, this is the kit for you.
Solid, High Quality Product. This Zone Offroad Suspension System includes a pair of fully-boxed, heavy-duty cross-members and ductile iron steering knuckles engineered to work with the redesigned steering. A 3-piece differential relocation system is utilized to correct front pinion angle with the center differential brace tying front and rear cross-members together for a sturdy differential mount. This coupled with the differential skid plate and cross-member brace create an incredibly strong front subframe designed to correct suspension geometry while increasing ground clearance.
Installation. Professional installation is recommended. It should be noted that cutting and drilling is required for installation. With all the necessary hardware included, this Lift kit can be installed in about 8-10 hours time. An alignment is required prior to driving the vehicle.
Technical Notes. Factory 17- and 18-inch wheels cannot be reinstalled due to tie rod end interference. 17x9 aftermarket wheels with a 5-inch backspacing or 18x9 aftermarket wheels with a 5-inch backspacing are recommended. To reduce the need for trimming, 20-inch wheels with 5.75-inch backspacing are recommended.
Application. This Zone Offroad 4.50-Inch Suspension Lift with Nitro Shocks is specifically engineered to fit 2020-2022 4WD 6.2L, 7.3L F-250 Super Duty models.
Solid, High Quality Product. This Zone Offroad Suspension System includes a pair of fully-boxed, heavy-duty cross-members and ductile iron steering knuckles engineered to work with the redesigned steering. A 3-piece differential relocation system is utilized to correct front pinion angle with the center differential brace tying front and rear cross-members together for a sturdy differential mount. This coupled with the differential skid plate and cross-member brace create an incredibly strong front subframe designed to correct suspension geometry while increasing ground clearance.
Installation. Professional installation is recommended. It should be noted that cutting and drilling is required for installation. With all the necessary hardware included, this Lift kit can be installed in about 8-10 hours time. An alignment is required prior to driving the vehicle.
Technical Notes. Factory 17- and 18-inch wheels cannot be reinstalled due to tie rod end interference. 17x9 aftermarket wheels with a 5-inch backspacing or 18x9 aftermarket wheels with a 5-inch backspacing are recommended. To reduce the need for trimming, 20-inch wheels with 5.75-inch backspacing are recommended.
Application. This Zone Offroad 4.50-Inch Suspension Lift with Nitro Shocks is specifically engineered to fit 2020-2022 4WD 6.2L, 7.3L F-250 Super Duty models.
Fitment:
DetailsZone Offroad ZONF59N
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (2) Lift Blocks
- (2) Shocks
- (2) Crossmembers
- (2) CV Axle Spacers
- (1) Skid Plate
- (2) Steering Knuckles
- (1) Installation Hardware
4.7
Customer Reviews (51)
Questions & Answers
No questions about this product yet.
Ask the First Question
Will It Fit My F-250
- 6.2L V8 - 20, 21, 22
- 7.3L V8 - 20, 21, 22
