Find Shocks & Struts for your Sierra 1500
Rancho RS9000XL Rear Shock for 4.50-Inch Lift (14-18 4WD Sierra 1500)Find parts that fit my vehicle
Item S512250-2
Sierra 1500 Sales Techs:
Connect Now
M-F 8:30A-11P, Sat-Sun 8:30A-9P
$0.00
25 Reviews
Our Price
$125.12 each
Ship to: 43215
Please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.
Will this fit your Vehicle?
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Product Information
Features, Description, Reviews, Q&A, Specs & Installation
Features & Specs
- RS9000XL Series Shock Absorber
- Improves Handling and Performance
- Maintains Comfortable Ride Quality
- Designed for 4.5-inch Lifts
- Nine Position Adjustable Damping
- Tri-Tube Gas Pressurized Shock
- White Powder Coated Finish with Red Polyvinyl Boot
- Direct Bolt-On Replacement
- Sold Individually - (1) Rear Shock
- Limited Lifetime Manufactures Warranty
- Fits 2014-2018 4WD GMC Sierra 1500 Models
| Brand | Rancho |
| Shock Type | Adjustable |
| Shock Lift Height | 4.50-Inch Lift |
Description
RS9000XL Series Rear Shock. Rancho is proud to offer the RS9000XL Series Rear Shock as a premium performance upgrade for your Sierra. This RS9000XL Series Rear Shock Absorber will greatly improve the handling performance and ride quality of your ride. Designed for Sierras with a 4.5-inch lift, this adjustable Shock is straight forward to install and will work in conjunction with your original factory and aftermarket suspension parts.
Nine Position Adjustable Damping. The adjustable option of the Rancho RS9000XL Rear Shock allows you to adjust damping with just a twist of a knob giving you 9 shocks in one. The adjustment knob provides a clear understanding of each tuning level with settings 1-3 = on/off-road flexibility, 4-6 = similar to RS5000 shocks, and 7-9 = performance/towing flexibility. This damping adjustability will elevate the overall handling and performance of your vehicle both on and off-road, giving you the confidence you need to put your Sierra through its paces.
Quality Construction. Manufactured using a gas pressurized tri-tube design, this Rancho Shock features a 18mm nitro-carburized piston rod with a 1-1/4-inch diameter sintered iron piston to provide heightened control. Rancho Shocks feature a larger, 2-3/4-inch diameter shock body that allows for increased fluid capacity to operate cooler with increased vehicle control. The combination of all-weather fluid and low-friction, self-lubricating seals help prolong performance and allow for quicker rebound and smoother compression during the shock cycle. The Shock is completed in durable, white powder coated finish with a red polyvinyl accordion protection boot for impressive good looks and long lasting durability.
Direct Bolt-on Replacement. Rancho designed their Shocks to be a direct bolt on replacement for your Sierra’s factory shock absorbers. Please note that an alignment, by a qualified shop, is highly recommended after installation.
Application. This Rancho RS9000XL Rear Shock for 4.5-Inch Lift is designed to fit 2014-2018 4WD GMC Sierra 1500 models with a 4.5-inch suspension lift. Sold individually.
Nine Position Adjustable Damping. The adjustable option of the Rancho RS9000XL Rear Shock allows you to adjust damping with just a twist of a knob giving you 9 shocks in one. The adjustment knob provides a clear understanding of each tuning level with settings 1-3 = on/off-road flexibility, 4-6 = similar to RS5000 shocks, and 7-9 = performance/towing flexibility. This damping adjustability will elevate the overall handling and performance of your vehicle both on and off-road, giving you the confidence you need to put your Sierra through its paces.
Quality Construction. Manufactured using a gas pressurized tri-tube design, this Rancho Shock features a 18mm nitro-carburized piston rod with a 1-1/4-inch diameter sintered iron piston to provide heightened control. Rancho Shocks feature a larger, 2-3/4-inch diameter shock body that allows for increased fluid capacity to operate cooler with increased vehicle control. The combination of all-weather fluid and low-friction, self-lubricating seals help prolong performance and allow for quicker rebound and smoother compression during the shock cycle. The Shock is completed in durable, white powder coated finish with a red polyvinyl accordion protection boot for impressive good looks and long lasting durability.
Direct Bolt-on Replacement. Rancho designed their Shocks to be a direct bolt on replacement for your Sierra’s factory shock absorbers. Please note that an alignment, by a qualified shop, is highly recommended after installation.
Application. This Rancho RS9000XL Rear Shock for 4.5-Inch Lift is designed to fit 2014-2018 4WD GMC Sierra 1500 models with a 4.5-inch suspension lift. Sold individually.
Fitment:
- 2014 GMC Sierra 1500
- 2015 GMC Sierra 1500
- 2016 GMC Sierra 1500
- 2017 GMC Sierra 1500
- 2018 GMC Sierra 1500
Rancho RS999297
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) Rear Shock Absorber
4.9
Customer Reviews (25)
Questions & Answers
No questions about this product yet.
Ask the First Question
Will It Fit My Sierra 1500
- 4.3L V6 - 14, 15, 16, 17, 18
- 5.3L V8 - 14, 15, 16, 17, 18
- 6.2L V8 - 14, 15, 16, 17, 18
