Installation Time
(approx) 5 Hours
Difficulty Level:
Mechanical expertise or professional installation required.
Guaranteed 12/24 Delivery Still Available see item page for details! available on most items - Details
Talk to a Sierra 1500 Sales Tech
1-888-706-1096
M-F 8:30A-11P, Sat-Sun 8:30A-9P
Find Lowering Kits for your Sierra 1500
Max Trac Lowering Kit; 3 to 4-Inch Front / 5 to 6-Inch Rear (07-18 Sierra 1500, Excluding 14-18 Denali)Find parts that fit my vehicle
Item S510934-A
Sierra 1500 Sales Techs:
Connect Now
M-F 8:30A-11P, Sat-Sun 8:30A-9P
$0.00
29 Reviews
Our Price
$786.43
Ship to: 43215
Please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.
Will this fit your Vehicle?
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Product Information
Features, Description, Reviews, Q&A, Specs & Installation
Features & Specs
- Lowering Kit
- Lowers Front by 3 to 4 Inches and Rear by 5 to 6 Inches
- Boosts Handling and Aerodynamics
- Rear Lowering Shock Absorbers
- Heavy-Duty Lowering Steel Coil Springs
- Robust Iron Drop Spindles
- Brawny Upper and Lower Control Arms
- Rigid Rear Shock Extenders
- Rear Flip Kit
- Professional Installation Recommended
- Limited Lifetime Warranty
- Fits All 2007 to 2018 GMC Sierra 1500 Models, Excluding the 2014 to 2018 Denali
| Brand | Max Trac |
| Lowering Kit Includes Shocks | Shocks Included |
| Lowering Kit Estimated Drop | 4.0F / 6.0R |
Description
Boost Your Handling. Boost the handling and aerodynamics of your Sierra 1500 when you install the Max Trac 3 to 4-Inch Front / 5 to 6-Inch Rear Lowering Kit. This lowering kit gives your truck a more streamlined profile that not only looks awesome but also gives you better control, especially when cornering. This lowered stance is especially ideal for dedicated street-driven trucks.
High-Quality Rear Lowering Shock Absorbers. This lowering kit includes a pair of lowering shock absorbers for the rear. These shocks by Max Trac feature a twin-tube pressurized gas design and a larger diameter piston. This design offers excellent damping performance while also greatly reducing the chances of cavitation. Additionally, these shocks come with chrome-hardened piston rods for superior strength.
Heavy-Duty Front Lowering Coil Springs. One of the components providing your truck with its lowered stance is the pair of lowering coil springs. These coil springs feature a progressive rate design and are manufactured from heavy-duty spring steel for strength. Also, these springs receive a tough black powder coat finish for corrosion protection.
Robust Drop Spindles. To ensure your truck’s steering geometry is maintained at near factory levels, this lowering kit includes a pair of drop spindles upfront. These spindles are designed to compensate for your truck’s steering geometry with its new lowered stance. Additionally, these spindles are cast from high-grade ductile iron for durability and are finished in a protective black powder coating.
Brawny Upper and Lower Control Arms. Another set of components helps realign your truck’s steering angles, and these are the steel upper and lower front control arms. These cast control arms offer exceptional strength and include new high-quality control arm bushings and ball joints that are outfitted with grease zerks for easy maintenance.
Rigid Rear Shock Extenders. A pair of shock extenders are included to take care of the rear suspension. These extenders work to relocate your shocks in an optimal manner, guaranteeing an ideal damping performance. As for the components' durability, these shock extenders are precision-fabricated from steel for strength and are finished in the same black powder coating as the rest of the components for optimal corrosion protection.
Rear Flip Kit. This lowering kit also includes a rear flip kit which is one of the main components responsible for lowering your rear. This kit achieves this by “flipping” your truck’s axle in relation to its leaf springs. Doing so doesn’t just lower your rear, but also maintains ideal suspension geometry.
Professional Installation Recommended. Installing this Max Trac lowering kit will require expert-level mechanical skills, as well as some specialized tools. As such, professional installation is recommended.
Comes with a Limited Lifetime Warranty. This Max Trac lowering kit comes with a limited lifetime warranty covering workmanship and material defects. Please visit the manufacturer’s website for more details.
Application. The Max Trac 3 to 4-Inch Front/5 to 6-Inch Rear Lowering Kit fits all 2007 to 2018 GMC Sierra 1500 models, excluding the 2014 to 2018 Denali.
Shop All Truck Parts And Accessories
Shop All Truck Lowering Kits
Shop All Truck Suspension
Fitment:
- 2007 GMC Sierra 1500
- 2008 GMC Sierra 1500
- 2009 GMC Sierra 1500
- 2010 GMC Sierra 1500
- 2011 GMC Sierra 1500
- 2012 GMC Sierra 1500
- 2013 GMC Sierra 1500
- 2014 GMC Sierra 1500
- 2015 GMC Sierra 1500
- 2016 GMC Sierra 1500
Max Trac K331336S
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (2) Rear Lowering Shocks
- (2) Rear Shock Extensions
- (1) Rear Flip Kit
- (2) Rear Adjustable Lift Hangers
- (2) Front Lowering Coil Springs
- (2) Front Drop Spindles
- (2) Front Upper Control Arm Assemb
4.4
Customer Reviews (29)
Questions & Answers
No questions about this product yet.
Ask the First Question
Will It Fit My Sierra 1500
- 4.3L V6 - 07, 08, 09, 10, 11, 12, 13, 14, 15, 16
- 4.8L V8 - 07, 08, 09, 10, 11, 12, 13
- 5.3L V8 - 07, 08, 09, 10, 11, 12, 13, 14, 15, 16
- 6.0L V8 - 07, 08, 09, 10, 11, 12, 13
- 6.2L V8 - 07, 08, 09, 10, 11, 12, 13, 14, 15, 16
