How to Install ZRoadz Hood Hinges Mounting Kit w/ Two 3 in. LED Light Cubes (07-13 Silverado 1500) on your Chevy Silverado

- (1) Driver Side Light Mount Bracket
- (1) Passanger Side Light Mount Bracket

START HERE: Turn off engine, chalk tires with stop block, open the hood and disconnect the battery.

1) Begin by marking the relation between the hinge and hood. Use a piece of tape so you can ensure proper hood alignment when installation is complete.

2) Loosen the two bolts securing the hood hinge to the under belly of hood.

Do not remove hardware. Only back out threads a few turns.

3) Secure bracket to hood hinge with factory bolts by sliding LED Mounts into place. Make sure the brackets are on the bottom side of hinge and NOT inbetween hinge and hood.Repeat on opposite side of vehicle.

4) Mount LED Lights onto each of the brackets. For Now, Hand tighten mounting bolts.

PRO TIP: You may consider mounting Light Pod onto bracket first, and then slide into position from cab side.

STEP 5: Wire LED Light with a ZROADZ optional wiring harness kit (part# Z390020S-A) or by utilizing a compatible custom wiring harness. ZROADZ recommends LED Lights be wired with ZROADZ harness kit (part# Z390020S-A).

6) To adjust the angle of your Light Bar, rotate the LED(s) to adjust the angles till your desired light pattern is reached. You may than tighten the hardware and also mounting bracket to hood and secure everything into place. Note your tape marker under hood to check for proper alignment. Be careful not to over tighten the mounting hardware.

It is best to adjust the angle with the vehicle on level ground with lights facing a wall, garage door or other solid barrier. We recommend checking from a distance of 25’. Your installation is now completed.
