Rancho RS9000XL Rear Shock for 3 to 4-Inch Lift (17-20 4WD F-150, Excluding Raptor)Find parts that fit my vehicle

Item T546351-4
Product Image
Rancho RS9000XL Rear Shock for 3 to 4-Inch Lift (17-20 4WD F-150, Excluding Raptor)
Verify parts fit and get product recommendations.
F-150 Sales Techs: Connect Now M-F 8:30A-11P, Sat-Sun 8:30A-9P
Call now 1-888-706-1096 Chat Now
$0.00
25 Reviews
Our Price

$125.12 each

to: 43215
Please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.

Will this fit your Vehicle?

Select a different vehicle Help?
Update or Change Vehicle
Add to Cart
Save for later
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Loading Indicator

    Frequently Bought Together

      Product Information

      Features, Description, Reviews, Q&A, Specs & Installation

      Features & Specs

      • RS9000XL Series Shock Absorber
      • Improves Handling and Performance
      • Maintains Comfortable Ride Quality
      • Designed for 3 to 4-inch Lifts
      • Nine Position Adjustable Damping
      • Tri-Tube Gas Pressurized Shock
      • White Powder Coated Finish with Red Polyvinyl Boot
      • Direct Bolt-On Replacement
      • Sold Individually - (1) Rear Shock
      • Limited Lifetime Manufactures Warranty
      • Fits 2017-2020 4WD F-150 Models, Excluding Raptor

      Description

      RS9000XL Series Rear Shock. Rancho is proud to offer the RS9000XL Series Rear Shock as a premium performance upgrade for your F-150. This RS9000XL Series Rear Shock Absorber will greatly improve the handling performance and ride quality of your F-150. Designed for 3 to 4-inch lifts, this adjustable Shock is straight forward to install and will work in conjunction with your original factory and aftermarket suspension parts.

      Nine Position Adjustable Damping. The adjustable option of the Rancho RS9000XL Rear Shock allows you to adjust damping with just a twist of a knob giving you 9 shocks in one. The adjustment knob provides a clear understanding of each tuning level with settings 1-3 = on/off-road flexibility, 4-6 = similar to RS5000 shocks, and 7-9 = performance/towing flexibility. This damping adjustability will elevate the overall handling and performance of your vehicle both on and off-road, giving you the confidence you need to put your F-150 through its paces.

      Quality Construction. Manufactured using a gas pressurized tri-tube design, this Rancho Shock features a 18mm nitro-carburized piston rod with a 1-1/4-inch diameter sintered iron piston to provide heightened control. Rancho Shocks feature a larger, 2-3/4-inch diameter shock body that allows for increased fluid capacity to operate cooler with increased vehicle control. The combination of all-weather fluid and low-friction, self-lubricating seals help prolong performance and allow for quicker rebound and smoother compression during the shock cycle. The Shock is completed in durable, white powder coated finish with a red polyvinyl accordion protection boot for impressive good looks and long lasting durability.

      Direct Bolt-on Replacement. Rancho designed their Shocks to be a direct bolt on replacement for your F-150’s factory shock absorbers. Please note that an alignment, by a qualified shop, is highly recommended after installation.

      Application. This Rancho RS9000XL Rear Shock for 3 to 4-inch Lift is designed to fit 2017-2020 4WD Ford F-150 models, excluding Raptor, with a 3 to 4-inch lift. Sold individually.

      Fitment:

      Details

      Rancho RS999287

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      What's in the Box

      • (1) Rear Shock Absorber
      4.9

      Customer Reviews (25)

      Questions & Answers

      No questions about this product yet. Ask the First Question

      Will It Fit My F-150

      • 2.7L V6 EcoBoost - 17, 18, 19, 20
      • 3.0L V6 Power-Stroke - 18, 19, 20
      • 3.3L V6 - 18, 19, 20
      • 3.5L V6 - 17
      • 3.5L V6 EcoBoost - 17, 18, 19, 20
      • 3.5L V6 EcoBoost Limited - 19, 20
      • 3.5L V6 EcoBoost Raptor - 17, 18, 19, 20
      • 5.0L V8 - 17, 18, 19, 20
